18965

Ball valve, type PE, PN16

MODEL: 1010
MANUFACTURER:
Clear

Seats: HDPE | O−rings: EPDM

Material: Unplasticised polyvinyl chloride (PVC-U).

Dimensions: All sizes according to EN 1452.

Hydraulic test: In accordance with UNE-EN 917.

Work Conditions:

  • Cement joint fittings:
    From 16mm to 140mm = PN16.
    From 160mm to 315mm = PN10.
  • Threaded fittings:
    All sizes PN10.

Assembly:

  • The use of PTFE film is recommended for threaded fittings.
  • The use of a Tetrahyrofurane adhesive for solvent cement fittings (CH-Adhesive) is recommended.
Please select product code
Expression of Interest Form

In case you are a professional, fill in the name of your company.









    * Obligatory fields

    Dimensions & Performances
    CodeDNAFHLØ
    1010016106114559516
    1010020156116559520
    10100252061195810225
    10100322582227711532
    10100403282268113040
    1010050401103110714450
    1010063501103811316663
    1010075 (PN10)651524415222475
    1010090 (PN10)651525115223290
    1010091 (PN10)801525116324690
    1010100 (PN10)8015261163264110
    1010125 (PN10)10028461180308125
