Branch 45° with O-ring

Name: Branch 45° with O-ring
SKU: 213110110453
Price: 1.00 EUR
Availability: InStock

MODEL: 213110110453

Pipes for domestic and street sewerage systems together with the appropriate coupling sleeves are intended to be used for the removal of all kinds of wastewater.

They are produced from unplasticized polyvinyl chloride (PVC-U).

Please select product code

Expression of Interest Form

In case you are a professional, fill in the name of your company.

ZOOM IN

Code	D/D1	S	Z 1	Z 2	Z 3	I 1 min	I 2	I 3
213110110453	110/110	3,3	22,8	138,2	138,2	61	49,1	49,1
213125110453	125/110	3,3	15,3	148,8	145,7	68	54,6	49,1
213125125453	125/125	3,3	25,9	156,3	156,3	68	54,6	54,6
213160110453	160/110	4	1	168	159	81	86	61
213160125453	160/125	4	12	176	169	81	86	72
213160160453	160/160	4	36	194	194	81	86	86
213200110453	200/110	4,9	-16	195	177	99	106	61
213200125453	200/125	4,9	7	212	201	81	106	72
213200160453	200/160	4,9	19	220	213	99	106	86
213200200453	200/200	4,9	46	241	241	99	106	106
213250110453	250/110	6,2	32	228	209	165	128	61
213250125453	250/125	6,2	21	236	220	154	128	72
213250160453	250/160	6,2	-4	253	236	125	128	86
213250200453	250/200	6,2	23	274	264	125	128	106
213250250453	250/250	6,2	57	300	300	125	128	128
213315110453	315/110	7,7	2	272	244	160	155	61
213315125453	315/125	7,7	-8	279	254	154	155	72
213315160453	315/160	7,7	-32	297	278	126	155	86
213315200453	315/200	7,7	-6	318	295	132	155	106
213315250453	315/250	7,7	28	344	331	132	155	128
213315315453	315/315	7,7	72	378	378	132	155	155
