Specifications
- Very fine filtration (between 20 and 25 microns).
Dimensions & Performances
ZOOM IN
| Model | Flow rate (m³/h) | Α (mm) | B (mm) | C (mm) | D (mm) | E (mm) | F (mm) |
|---|---|---|---|---|---|---|---|
| C0250EURO | 5,7 | 235 | 203 | 267 | 508 | 117 | 57 |
| C0500EURO | 11,3 | 235 | 203 | 267 | 749 | 117 | 57 |
| C0751EURO | 17,0 | 286 | 267 | 330 | 745 | 140 | 89 |
| C0900EURO | 20,4 | 286 | 267 | V | 746 | 140 | 89 |
| C1200EURO | 27,2 | 286 | 267 | 330 | 902 | 140 | 89 |
| C17502EURO | 39,7 | 286 | 267 | 330 | 1009 | 140 | 89 |
